Westgate RSL4-MCT5-ORB

RSL4-MCT5-ORB Product

Westgate Lighting 4″ Round LED Ultra Slim Recessed Light, Multi Color Temperature, Oli-Rubbed Bronze Finish

SPECIFICATIONS:

• Voltage: 120V AC
• Output Voltage: 36VDC
• Power Factor: >0.90
• Wattage: 9W
• Efficacy: 70 LPW
• Total Harmonic Distortion: ≤15 %

FEATURES:

•Dimming: Dimmable Down to 10% Using a Standard TRIAC LED Dimmer
• Lens: 0.125” White Translucent Acrylic
• Can Rotate after Installation to Align
• LED: Seoul DOB (Driver On Board) Technology
• Optics: White Translucent Acrylic
• Total Lumens: 630LM
• Color Temperatures: 2700K/ 3000K/ 3500K/ 4000K/5000K
• Multi CCT (Selectable Switch on the Back of the driver )
• Color Rendering Index: CRI ≥ 80
• Beam Angle: 100°-110°
• Rated life: 50,000 hrs

HOUSING SPECIFICATIONS:
•1/4”Thick
• Up to 9 AWG18 Wires
• Die-cast Aluminum with white powder coat finish
• Pot Light Housing is Not Required Even for Insulated Ceiling
• Junction box 1” Thick Included with Fixture
• TypeI Crated: Approved for direct contact with insulation
• Maximum Ambient Temperature: -40°F to 104°F
• Damp Location

WARRANTY: 5 years
