Westgate CDLX-MD-15-45W-30K

CDLX-MD-15-45W-30K Product

Ideal for indoor parking lots, commercial buildings, schools, warehouses, retail centers, apartment complexes. Designed for 9 to 16-foot mounting.

SPECIFICATIONS:

ELECTRICAL SPECIFICATIONS:
• Wattage: 15W/ 25W/ 35W/ 45W
• Input Current: 0.6A MAX
• Input Voltage: 120-277VAC 50/60Hz
• Power factor: >0.90
• LPW: 120

Mechanical:
• Die-cast aluminum with bronze
• Four 1/2” threaded hubs located on four sides of
the housing
• Prismatic polycarbonate lens
• Lifespan: 70000 Hrs
• Operating temperature: -4°F ~ 104°F
• IP rating: IP65, Wet Locations

Lighting:
• Dimming: 0~10V dimmable
• LED type/ Brand: SMD 3030/ Philips Lumileds LEDs
• Total lumens: 3000LM Max.
• Color temperature: 3000K/ 4000K/ 5000K
• Color rendering index: >80
• Beam angle: 150°
• Lifespan: 70000 Hrs

WARRANTY: 7 years
