WAC LED-TE24 InvisiLED® Pro 3 24V Foldable High Output Tape Light 1FT
Original price was: $43.95.$13.19Current price is: $13.19.
Description
InvisiLED® Pro 3 24V Foldable High Output Tape Light System
A specification grade tape light that is designed for task or accent lightingapplications. This tape can be folded to create customized patterns with thehelp of LED-T-CL1 clips for a flattering look. Pro3 is equipped with evenlyspaced diodes at 1” on the center to prevent dark spots and can be field-cut at6″ at the end of a run to perfectly fit into your interior space.
- 2700K, 3000K, 3500K, 4500K
- CRI: 95
- Power: 5W/FT
- Input: 24 VAC/DC
- Rated Life: 70000 Hours
- Both sides of field cut material can be used with male to male adapter
- Foldable design for lateral pattern creation
- Ultra thin profile at 1/8″. 90° fold height of 3/8″
- Diodes spaced evenly at 1″ on center
- May be field cut every 6″ at the end of a run
- Transformer required
- Can be mounted on ceiling or wall in all orientations
Spec Sheet
Spec SheetInstallation Instructions
Info
| Catalog No. | Lumens | Kelvin | Max. Run |
|---|---|---|---|
| LED-TE2430-1-WT | 395 | 3000K | 20FT on 100W Transformer 12ft on 60W transformer |
| LED-TE2435-1-WT | 440 | 3500K | 20FT on 100W Transformer 12ft on 60W transformer |
| LED-TE2445-1-WT | 475 | 4500K | 20FT on 100W Transformer 12ft on 60W transformer |
Accessories
| MODEL | DESCRIPTION |
|---|---|
| EN-24100-RB2-T – 60 | Remote Enclosed Electronic Transformer for InvisiLED® Tape Light 120V Input 24V Output 60 Watt |
| EN-24100-RB2-T – 100 | Remote Enclosed Electronic Transformer for InvisiLED® Tape Light 120V Input 24V Output 100 Watt |
Accessories
| Catalog No. | |
|---|---|
| LED-TC-EC | 1 cut and 1 male end cap |
| LED-TC-L-WT | “L” Connector |
| LED-TC-IC2 | 2″ Joiner |
| LED-TC-IC6 | 6″ Joiner |
| LED-TC-MM | Male to male connector |
