Description
110W LED 2FT LINEAR HI-BAY
LED 2 ft. Linear Hi-Bay- 110W- 40K/50K – White Finish – 100-277V
| Status |
Active |
| Fixture Type |
Linear Hi-Bay |
| Finish |
White |
| Wattage |
110W |
| Lumen Output |
14000L |
| CCT (Kelvin) |
40K/50K |
| IP Rating |
IP20 |
| Indoor or Outdoor Fixture |
Indoor |
Spec Sheets
| Color Temp. |
Spec Sheet |
| 40K |
65-503 |
| 50K |
65-504 |
Installation Instructions
Info
| Technology |
LED |
| Wattage |
110W |
| Lumen Output |
14000L |
| CCT (Kelvin) |
40K/50K |
| Color Temperature |
Cool White/Natural Light |
| CRI |
80 |
| Voltage |
100V-277V |
| Rated Hours |
50000 |
| Operating Temperature |
-20C (-4F) to a maximum of +45C (+113F) |
| Dimmable |
Yes-Dimmable |
| Dimming Note |
0-10V Dimming Only; Dimming range from 100 to less than or equal to 20 percent depending on dimmer control |
| Weight (lb.) |
8.71 |
| IP Rating |
IP20 |
| Height (in.) |
3.00 |
| Width (in.) |
12.60 |
| Length (in.) |
23.82 |
Additional Info
| Safety Listing |
cULus |
| Location Rating |
Damp |
| Energy Star |
No |
| DLC Approved |
Yes |
| DLC ID |
40K PL04BEXRD7VZ
50K PLTQCBT8S2G0
|
| CA T20 / T24 Rationale |
T20 Exempt – Fixtures Not Regulated |
| California Status |
Lawful for sale in California |
| California Prop 65 |
Lead |
| RoHS Compliant |
Yes |
| FCC Compliant |
Yes |
Additional Information
| Includes |
(2) 48 inch Chain; (2) V-Clips; (1) 1.02 inch Mounting Bracket |
| Warranty |
5 Year Limited – Fixtures |
