Description
EXIT-NY
New York City Approved exit sign with a universal face and red letters.
Spec Sheets
|
Standard |
Emergency |
| Red |
Spec Sheet
Installation Instructions
|
Spec Sheet
Installation Instructions
|
Info
| Product Type |
New York City Compliant Exit Sign |
| Wattage |
5W @120V and 277V |
| Mounting |
Back/Top/End |
| Mounting Type |
Wall/Ceiling Mount |
| Battery Backup |
Depending on trim
- AC Only
- 90 Min Battery Backup(24HR Recharge Time)
|
| Housing Material |
Steel Sheet |
| Number of Faces |
Universal Single/Double Face |
| Letter Color |
Red |
| Remote Capacity |
No Remote Capacity |
Additional Info
Compliance
| Safety Listing |
UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards |
| Environment |
Suitable for indoor use in dry and damp environments |
| IP Rating |
Indoor |
| Model Number for Certification |
|
| T20 Compliant |
Can be used to conform with the requirements of California Title 20 |
| CEC Status |
Lawful for Sales in California |
| City Compliance |
New York City Approved |
|
Electrical
| THD |
≤20% |
| Power Factor |
≥0.9 @ 120V; ≥0.4 @ 277V |
| Input Voltage |
Dual 120/277 Voltage |
| Operating Temperature |
32°F to 122°F (0°C to 50°C) |
| Dimming |
TRIAC and ELV dimming compatibility |
|
