Prescolite LBSE-4SQD LiteBox Edge-Lit 4″ 10.1W LED Square Surface Mount Downlight

Description

LiteBox Edge-Lit surface mount downlights affordably combine LED edge-lit technology and contemporary appearance with ease of installation and versatility.

Features

• Finish: White
• Wattage: 10.1W
• Voltage: 120-277V
• Color Temperature: 3000K
• Lumen: 750
• CRI: 80
• 120-277V 0-10V Dim to Off or 120V Triac or ELV phase cut to 5%
• Low surface profile of 1/2″
• Quick snap installation with no housing required
• Installs directly to most 3-1/2″ and 4″ J-Boxes

Dimension

• Width: 4.61″
• Height: 0.48″

Estimated Life

• Maintains 80% of lumen output at 54,000 hours of operation, L80 at >54,000 hours (TM-21)

Warranty

• 5-year warranty

Documents

• Spec Sheet
• Instruction Sheet
• LBSE-SQD BIM file
