NX Lighting Controls ALCR1277 UL924 Automatic Load Control Relay
Original price was: $138.08.$34.52Current price is: $34.52.
Description
UL924 Automatic Load Relay allows emergency lighting to be controlled with normal lighting. Ensuring that the emergency lighting will be forced to full bright upon loss of normal power.
Features
- Color: Black
- Voltage: 120/277V
- Meets NEC Article 700 requirements for emergency lighting
- Normally closed contacts for emergency lighting
- Normally open contacts for 0–10V dimming override
- Provision for remote test button or fire alarm interface
- Multi-color function LED
- Suitable for use in return air plenums
Dimensions
- Width: 3.28″
- Height: 1.74″
- Depth: 3.39″
Warranty
- 5Years Limited Warranty
Documents
- Spec Sheet
- Instruction Sheet
