Description

Nora Lighting NPTCB-E22/40AW

NPTCB-E22/40AW Product

The LED energy efficient Center Basket Troffer is a specification grade architectural product. The recessed LED center basket troffer provides smooth and uniform general lighting for commercial and industrial applications. The shallow housing design and easy access wiring plate make the center basket a quick installation. The LED center basket troffer performance is suitable for office, school, retail, hospital and hospitality applications.

FEATURES

· Available in three sizes (1′ x 4′, 2′ x 2′ or 2′ x 4′)
· 3400lm, 4000lm or 6100lm LED packages
· 3000K, 3500K, 4000K or 5000K @ 85 CRI
· 5-year limited warranty
· DLC Listed
· Integral 0-10V dimmable driver
· Optional emergency option

SPECIFICATION

Housing: Die form steel powder coated in matte white reflective surface for soft uniform reflectance. Enclosed driver
compartment is easily accessible from below via a hinged LED platform. Built in earthquake clips.
Lens: Polycarbonate diffused white lens evenly distributes light and maximizes performance. Diffused lens reduces glare
and offers more balanced lighting, eliminating shadowy cave effects caused by parabolics.
Optics: Polycarbonate diffused white lens evenly distributes light and maximizes performance.

ELECTRICAL
Input Voltage: 120/277V
Power Factor: >0.90
Delivered Lumens / Wattage:
14 = 3400lm / 33W; 22 = 3400lm / 33W; 24L40 = 4000lm / 37W; 24 = 6100lm / 44W

Color Temperature : 3000K, 3500K, 4000K or 5000K
CRI : 85 CRI
Operating Temp : 0˚C to 45˚C ambient temperature
Dimming : 0-10V dimming down to 10%
Emergency : Optional battery and remote test switch will power luminaire for 90 minutes during power failure.
