MaxLite CN-RTMST

CN-RTMST Product

MaxLite 105564 Control Node Rectangular Microwave Motion Sensor /Photocell Translucent

Specifications:

Manufacturer: MaxLite
SKU: CN-RTMST
UPC: 767627007866
Operating Voltage: 12-20VDC
Operating Current: max 30mA
Sinking Current: max 25mA
Sensor Technology: Microwave (5.8GHz)*, Photoelectric
Control Output: 0-10V
Recommended Mounting Height: 8-15ft / 2.5-4.5M
Maximum Mounting Height: 35ft / 10M
Connector Interface: USB-C
Commissioning Protocol: IR
Certification: cULus Listed E511069 (Damp Listed), California Title 20 Compliant, FCC Part 15 Subpart B Class A
Operating Temperature: -30°F to 130°F / -35°C to 55°C
Operating Humidity: 0-85% RH Non-Condensing
Photocell: LOW(1FC) / MEDIUM(20FC) / HIGH(50FC) (PC OFF)
High Trim: 50%, 75%, 100%
Overall Dimensions: 1.91″ X 0.8″ X 0.57″ / 48.5mm X 20.5mm X 14.6mm
Color: Translucent
Weight: .45oz/12.8g

About MaxLite:

MaxLite has been committed to providing energy-efficient lighting products since 1993. One of the first movers into LED technology in the industry, MaxLite offers a complete portfolio of quality certified LED lamps, indoor and outdoor LED luminaires, and a full line of its patented cMax Lighting Controls.
