Description

Lotus LED Lights JXL-COB04-R15W-5CCT-BK-4RR-SM-AZ

JXL-COB04-R15W-5CCT-BK-4RR-SM-AZ Product

Compact 4-inch LED downlight with 5-step adjustable color temperatures (2700K-5000K), delivering up to 1420 lumens and 90+ CRI for crisp, vibrant lighting. Features TRIAC dimming (20%-100%), a Black trim, durable Alzak reflector, and airtight construction for damp/insulated ceilings. ETL-certified, operates in -4°F to 104°F, with a 30,000-hour lifespan and 3-year warranty.

Specifications:

Brand: Lotus LED Lights
Part Number: JXL-COB04-R15W-5CCT-BK-4RR-SM-AZ
UPC: 769152011141
Power: 15W
Color Temperature (K): 2700, 3000, 3500, 4000, 5000
Light Output WH Reflector (lm): 1180, 1300, 1380, 1420, 1380
Light Output BK Reflector (lm): 1170, 1270, 1350, 1380, 1340
Beam Angle: 36°
CRI: 90+
Driver Input: 120V AC, 50/60 Hz
J-Box Volume: 7.4 in³
Dimming: TRIAC Dimmers (20% – 100%)
Approved Location: Insulated Ceiling & Damp Locations
Air Tight: Yes
Ambient Temperature: -4°F (-20°C) to +104°F (+40°C)
Projected Life: 70% Light Output at 30,000 Hours
Certification: c ETL us
Warranty: 3 Years
Finish: Trim Black , Reflector Alzak

Features:

Model JXL-COB04-R15W-5CCT
5 CCT User Selectable 2700K-3000K-3500K-4000K-5000K
CRI 90+ for True Color Rendering
Type IC Rated – No Housing Required
120V Triac Dimmable Driver Included
Fast and Easy To Install – Save On Labor
3″ Deep – Install Where Ceiling Space Is Limited
Available with White & Black trims and 4 Smooth & 2 Baffle Reflectors
Driver Inside Connection Box – No Junction Box Needed
