Lithonia Lighting TWS 42W Triple-Tube Dark Bronze Outdoor Flood Wall Pack

Description

For entrances, stairwells, corridors and other pedestrian areas.

FEATURES:

Finish: Dark Bronze
Wattage: 42W
Lamping: TRT
Voltage: 120V
Control Options: Photoelectric cell
Construction: Cast aluminum backplate on which electrical components are mounted for maximum heat dissipation. Gasketing between backplate and front cover prevents entry of water and comtaminants. External hardware includes Phillips head and tamperproof hex-head fasteners.
Socket: Porcelain, medium-base socket with copper alloy nickel-plated screw shell and center contact.
Installation: Units for wall mounting include two 3/4″ knockouts for routing electrical conduit back and bottom.

SPECIFICATIONS :

INTENDED USE

For entrances, stairwells, corridors and other pedestrian areas.

CONSTRUCTION

Cast aluminum backplate. Gasketing between backplate and front cover prevents the entry of water and contaminants. External hardware includes
phillips head and tamper-proof hex-head fasteners.

FINISH

Dark bronze (DDB) or white (DWH) front cover available for all wattages.

OPTICAL SYSTEM

Front cover/refractor is injection-molded, one-piece, UV-stabilized polycarbonate. The optical system is sealed and gasketed to inhibit the entrance of
outside contaminants.

ELECTRICAL SYSTEM

The 13W fluorescent uses a 120V electro-magnetic ballast and includes a
twin tube fluorescent lamp as standard. The 26/42W fluorescent uses a multivolt electronic ballast and offers the option of 120-277V operation and also
the option of 26W, 32W or 42W triple tube fluorescent lamp (not included).

INSTALLATION

Units are for wall mounting and include two 3/4″ knockouts for routing electrical conduit.

LISTING

UL listed for wet locations. Listed and labeled to comply with Canadian Standards.
