Lightolier C2L09DL Calculite 1.75″ LED Frame Light Engine

Description

Add detail and style to any space with Calculite LED 1.75″ aperture downlightsand optional Micro Vetro elements.

Features

• Complete luminaire = Frame + Trim or Micro Vetro (optional) + Installation Accessories (if required)
• Wattage: 13.9W
• Voltage: 120-277V
• Color Temperature: 3000K
• Lumen: 900
• CRI: 90
• Dimming: 0-10V dimming
• Install from below
• Power connection: Integral connection between driver and LED array
• Field replaceable optics: 4 TIR optics included for field installationand replacement (25°, 30°, 45° and 50° beams included)

Dimensions

• Aperture: 1.75″
• Width: 2.5″
• Ceiling cutout: 2.13″
• Thick ceiling capability: 0.38″ – 2″
• Fixture Weight: 1.8 lbs

Estimated Life

• 50,000 hours

Warranty

• 5 Year Limited

Documents

• Spec Sheet
• Instruction Sheet
