IOTA IIS-125-HE-SM, 125W Surface Mount Inverter for CA Title 20 Applications
Original price was: $866.25.$173.25Current price is: $173.25.
Description
The IOTA IIS 125 HE SM is a UL Listed stand-alone modified sine wave output inverter designed to provide power to designated emergency lighting fixtures. In a power loss situation, the IOTA IIS 125 HE SM will supply 125W of power from the onboard battery supply.
Features
- Input Voltage: 120/277V
- Output Power: 125W
- Output Voltage: 120/277V
- Lamps Operated:LED, Fluorescent, Incandescent
- Transfer Time:< 1 second
- Emergency Operation:90 mins
- Emergency lighting supplied from a single source
- Operates incandescent, LED, and fluorescent fixtures including fixtures with dimmable fluorescent ballasts
- Surface-mount design
- Includes momentary contact test switch, yellow ready indicator, green inverter-on indicator, and red charging indicator
- Replaceable output fuse protection
- High efficiency modified sine wave inverter
- Variable-rate charger
- Valve Regulated Lead Acid (VRLA) battery provides long life and is maintenance free
- Line voltage allows for remote mounting of emergency fixtures at distances up to 1000 feet
- Low Battery Voltage Disconnect and Line Latch Protection
- For use with switched or unswitched fixtures
Dimensions
- Length: 23.15″
- Width: 11.71″
- Height: 4.5″
- Weight:45 lbs
Document
- Spec Sheet
- Instruction Sheet
