Description

Intermatic IOS-DPBIMF-WH

IOS-DPBIMF-WH Product

The passive infrared sensors work by detecting the difference between heat emitted from the human body in motion and the background space. The sensor switch can turn a load ON and hold it as long as the sensor detects occupancy. After no motion is detected for the set time delay, the load turns OFF automatically. The sensor switch has one relay (equal to a single pole switch), and it also includes Ambient Light Level Sensor.

Specification:

Model Number IOS-DPBIMF-WH
Residential In-Wall Push Button PIR Occupancy Sensor, No Neutral Required, White
UPC Code 078275125315
Brand Intermatic
Warranty Period 2-Year limited
Country of Origin (Intermatic) CHINA
Control Specifications
Sensor Switch Type Occupancy
Sensor Technology PIR (Passive Infrared)
Adjustable Time Delay Min 15 sec
Adjustable Time Delay Max 30 min
Adjustable Light Level Min 30 lux
Adjustable Light Level Max Daylight
PIR Coverage Area (sq ft) 980
Application Compatibilities Incandescent; Fluorescent; CFL
Mechanical Specifications
Mount Type In-Wall
PIR Coverage Pattern (degrees) 150
Maximum Mounting Height (ft) 4 ft

About Intermatic:

Our product portfolio broadened to include industrial- and commercial-grade controls starting in 1990 and would soon expand with various progressive, energy-saving solutions. Today, Intermatic offers an extensive catalog of lighting and energy controls, surge protection devices, weatherproof covers, and Wi-Fi-enabled solutions as we evolve and push the industry forward.
