Description
4″ IC, Airtight, Ultra-Shallow Remodel, LED Housing, 120/277V
Recessed 4″ aperture ultra-shallow housing for use with LED integrated trims. Installs from below the ceiling and suitable for 2×4 residential or shallow plenum commercial construction. Suitable for direct contact with insulation; airtight rating reduces airflow between living spaces and unconditioned areas providing additional energy savings. Use with compatible Halo® LED integrated trims and modules providing general, task and accent lighting when energy savings, long life and optical control are required.
- Suitable for 2×4 framing or shallow plenum construction
- Suitable for below-the-ceiling installation
- Retractable mounting springs designed for easy installation or removal
- Quick Connect remodel wiring tray
- Hinged and captive door on junction box allows for easy access
- Insulated ceiling listed and Air-Tite
Spec Sheets
Spec Sheet
Installation Instructions
Info
| Lamp Type |
LED |
| Amperage Rating |
N/A |
| Aperture |
4 Inch |
| Mounting |
Recessed |
| Range of Motion |
N/A |
| Voltage Rating |
120-277V |
| Wattage |
15 W |
Additional Info
| Housing |
Die formed aluminum housing can be installed from below the ceiling and accommodate ceilings from 3/8” – 3/4” thick. Shipped with paint overspray protector installed. |
| Mounting Springs |
Captive preinstalled mounting springs retain housing securely in ceiling. Housing can be removed for service or splice inspection. |
| Gasket |
Closed cell gaskets achieve restrictive airflow requirements without additional caulking |
| Junction Box |
(2) 1/2″ trade size pry outs and (2) Slide-N-Side™ wire traps for nonmetallic cable. Accepts 14/2, 14/3, 12/2, 12/3 (US) and 14/2, 14/3, 12/2 (Canada) standard non-metallic sheathed cable. Maximum of (6) #12 or (8) #14 conductors rated for 90° C permitted in box (10in3 internal volume). Wago® push wire connectors for field connections. |
| Connector |
Two-conductor wire mount connector is rated for 120 – 277V and mates with Halo® LT4, RL4, RA4 and ML4 family of LED integrated trims. CAUTION – verify LED module input voltage is compatible with the input voltage of the housing. If uncertain, consult a qualified electrician |
Compliance
| Type IC inherently protected, suitable for direct contact to air permeable insulation and cULus listed for damp locations |
| Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013 |
| Wet location listed in covered ceilings and IP56 certified with select lens trim |
| Can be used for State of California Title 24 high efficacy luminaire compliance |
| Suitable for use in clothes closets when installed in accordance with the NEC 410.16 spacing requirements |
|
