ESL Vision ESL-WPHM-2565W-13050-WH-EM9

ESL-WPHM-2565W-13050-WH-EM9 Product

The Ambience™ Half Moon Architectural Wall Pack delivers versatile lighting with selectable wattage (25W, 45W, 65W) and CCT (3000K, 4000K, 5000K). It provides up to 9,100 lumens in up, down, or bi-directional modes and features a replaceable photocell, quick mount plate, visual comfort lens, and durable Whitefinish. With a 90,000-hour lifespan, emergency backup battery, auto-test function, and UL listing, it ensures reliable performance for wet locations.

Specifications:

Manufacturer: ESL Vision
SKU: ESL-WPHM-2565W-13050-WH-EM9
UPC: 196065199800
Selectable Wattage: 25W–45W–65W
CRI: >70
Selectable Kelvin: 3000K–4000K–5000K
Input Voltage: 120–277 VAC
Lumens:
– Up light: Up to 1,700 Lumens
– Downlight: Up to 6,500 Lumens
– Bi-Directional: Up to 9,100 Lumens
Weight (lbs):12.35 lbs
Dimensions (LxWxD):18.1″ x 9.25″ x 7.1″
L70 Lifetime: 90,000 Hours calculated per TM21
Efficacy: Up to 124 lm/W
Customizable Light Settings: Up/Down/Bi-Directional
Built-In Replaceable Photocell
Quick Mount Plate and Built-In Level
Visual Comfort Lens
Emergency backup battery unit
Auto test function
9-watt output
90-minute minimum
120–277 VAC input
10–300 VDC output
Open terminal block wiring
UL listed for factory or field install
Title 20 (SL1-OTB)
Finish: White
