ESL Vision ESL-HZLHB-L80W-250-HV-120D

ESL-HZLHB-L80W-250-HV-120D Product

The Hazard Series Linear High Bay Class 1 Div 2 provides 11,200 lumens at 80 Watt with 5000K color temperature and >70 CRI. Designed for hazardous environments, it operates on 200–480VAC with a 50/60Hz frequency. Featuring IK10 impact rating, marine-rated coating, and 10kV surge protection, it withstands temperatures from -40°F to 140°F. ABS certified, lightweight at 12.13 lbs, and built to last over 150,000 hours, it includes a 7-year warranty with a 10-year option. Dimensions: 47″x4.7″x9.5″.

Specifications:

Manufacturer: ESL Vision
SKU: ESL-HZLHB-L80W-250-HV-120D
UPC: 196065683248
Power: 80 Watts
Lumen Output: 11,200 Lumens
Efficacy (lm/W): Up to 140 Lumens per Watt
Kelvin: 5000K
Hazard Level: 2
CRI: >70
Power Frequency: 50/60Hz
Power Factor: >0.9
Operating Temperature: -40°F–140°F (-40°C–60°C)
Input Voltage: 200–480VAC
Life Span: >150,000 Hours
Warranty: 7 Year Warranty with 10 Year Option
Product Weight: 12.13 lbs
IK10 Impact Rated
ABS Certified
Marine Rated Powder Coating
Standard 10kV Surge Protection
Dimension: 47″x4.7″x9.5″

About ESL Vision:

Long-time friends and entrepreneurs, Mike Gleeson and Jeff Provolt, were very curious about the possible uses and benefits of LED tape light. They began to explore LED technology and discovered the need for cost-effective ways to save energy and money. By learning about the unique needs of electricians, end-users, and engineers, they were able to solve common problems through practical design.

In 10 short years, ESL Vision has grown from a basement operation to multiple warehouses with on-site assembly to provide the quickest turnaround times available on customized products. Thru their focus and dedication, ESL Vision has quickly become an industry leader in customer service and product innovation
