Description
96W Class2 Electronic Dimming Driver
The Emcod MLE96-24DC is a 96W Class 2 Electronic Dimming Driver capable of delivering power efficiently with optimal performance. With a 24V DC output this device provides reliable automation in commercial, industrial and residential applications.The Driver is ideal for outdoor electronic applications. It is UL-listed and comes with a black powder coated steel enclosure.
- 24V DC Constant voltage 96W hardwire LED drivers
- 5-in-1 with Triac forward and reverse phase, 0/1-10V , resistor, PWM
- Input leads are 18AWG 600V
- Output leads are 16AWG 300V
Spec Sheet
Spec Sheet
Installation Instructions
Info
| SERIESMLE-24DC | |
|---|---|
| Dimensions | |
| Weight | 3LBS |
| Length | 5.16″ |
| Width | 7.73″ |
| Height | 1.54″ |
| Electrical | |
| Input Voltage | 100-277V AC |
| Output Voltage | 24VDC |
| Max Load | 96W |
| Rating | cULus Listed (Wet Location) |
Additional Info
| Knockouts | Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable connectors |
| Input Voltage | 100-277V 50/60Hz |
| Max. input current at full load | 0.3A |
| Output voltage without load | 24.1VDC |
| Output voltage fully loaded | 24VDC |
| Max. Total Wattage | 80W Max |
| Max. Output Current | 4A |
| Efficiency | 90% |
| Load regulation | 1% |
| Ripple | 5% |
