Description

EMCOD MLE60-12DC-P

MLE60-12DC-P Product

EMCOD 60W Electronic Phase Cut Dimmable, Plastic Suitable For Dry And Damp Location Enclosure

Specifications:

Transformer
Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on
emcod.com
Temperature class F(155°C)
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C

Housing
The actual transformer 60W is encapsulated in the enclosure
The enclosure is Plastic suitable for dry and damp location, fit in 4″
junction box, IP20 rated
Enclosure Temperature does not exceed 95°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 1.57, W = 3.3, D = 0.98
Weight (LBs): 0.4
