EMCOD EDR96-24DC

EDR96-24DC Product

EMCOD 96W Electronic Class P Universal 5 in 1 dimming, Suitable For Dry And Damp Location Enclosure

Specifications:

Transformer
Dimmable with triac forward and reverse phase, 0/1-10V , resistor, PWM
Temperature class B(130°C)

Housing
The actual transformer 96W is encapsulated in the enclosure
The enclosure is Plastic suitable for dry and damp location, with built-in
class 2 wiring compartment, dry and damp location rated
Enclosure Temperature does not exceed 70°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 4.02, W = 2.1, D = 3.54
Weight (LBs): 0.84

About EMCOD:

EMCOD is a world-class developer and manufacturer of LED drivers, Lighting and custom made general-purpose transformers for electronic and electrical equipment. Emcod Lighting group’s advanced LED drivers and transformers bring innovation to commercial and residential lighting.
