Elco E1L02 Oak 1″ Round Recessed Downlight, Dim to Warm

Description

Features

• Housing sold separately
• Finish: White, Black with White Trim, Bronze, Haze with White Trim, Black
• Recessed Size: 1.25″
• Wattage: 6.1W
• Voltage: 12V
• Color Temperature: Sunset (Dim to Warm 2700K to 1800K)
• Lumens: 450 lm
• CRI: 93+
• Dimmable
• Beam Angle: 38°, 28°, 50°
• Requires 12V AC transformer. Dimmable ELV, MLV or 0-10V depending on transformer used.
• IC Airtight for use with direct contact to insulation
• Height allows for use in ceilings with under 3″ depth. Ceiling thickness can be reduced from fixture depth.
• Remodel requires no frame. New construction E1LF1 frame available.
• Construction: Diecast construction for lasting quality and greater heat dissipation.

Dimensions

• Width: 2.25″
• Height: 2.88″

Documents

• Spec Sheet
