Description

Eiko CSX1-8PS90-40-H

CSX1-8PS90-40-H Product

This 8-foot LED fixture offers an energy-efficient solution for replacing 2-lamp 86W T8 or 4-lamp 32W T8 fixtures. With lumen outputs ranging from 8,450 to 11,700 and an efficacy of 130 lm/W, it delivers bright and reliable lighting with a color temperature of 4000K. The fixture is designed for damp locations and features a durable white housing and acrylic lens. It supports 0-10V dimming for optimal lighting control and includes surge protection, making it a robust choice for commercial and industrial settings.

Specifications:

Brand: EiKO
Voltage: 120-347VAC
Lumens (lm): 11,700 / 9,750 / 8,450 lm
Wattage: 90W / 75W / 65W
Efficacy (lm/W): 130 lm/W
CCT: 4000K
CRI: 80+
Dimming: 0-10V
Nominal Size: 8 Foot
Replacement For/Equivalent: 2 lamp 86W T8 / 4 lamp 32W T8
IP Rating: IP20
Wet/Damp/Dry Location: Damp
Dimensions (L x W x H): 94 3/16″ (2392 mm) L, 2 13/16″ (72 mm) W, 2 1/2″ (64 mm) H
Housing Color: White
Lens Material: Acrylic (PMMA)
Operating Temp Range (°F/°C): -4°F to 122°F (-20°C to 50°C)
Driver Surge Protection (kV): L/N-PE: 2.5kV, L-N: 2.5kV
Auxiliary Output: 12V, 100mA
SKU: CSX1-8PS90-40-H
UPC: 31293137821

About Eiko:

EiKO, founded on entrepreneurial spirit over 46 years ago, has grown from a specialty lamp company to a leading provider of traditional lamps, LED lamps, fixtures, wireless sensors, and controls, serving industrial and commercial customers across the US and Canada. Agile and responsive to the ever-changing lighting industry, EiKO remains committed to delivering innovative solutions and exceptional customer experiences. With a strong focus on putting customers first, EiKO continues to evolve, expand its product offerings, and maintain its reputation for excellence, ensuring continued growth and success in an increasingly dynamic market.
