Diode LED SWITCHEX LED Driver and Dimmer Switch
Original price was: $107.55.$26.89Current price is: $26.89.
Description
SWITCHEX simplifies LED array lighting systems by combining an inwall LED dimmer switch and power supply into a single integrated unit. SWITCHEX mounts in a standard in-wall switch box, accepts 120V AC and converts to low voltage DC. SWITCHEX is compatible with most solid color 12V and 24VDC tape lights and fixtures.
Features
- Trim Plate and Switch Box sold separately.
- Output Voltage: 12V, 24V
- Power: 40W, 60W, 100V
- First LED Driver + In-Wall Dimmer Switch in one unit.
- Simplifies LED installation by eliminating compatibility issues between driver and dimmer.
- Fits in a standard recessed electrical box.
- 100% – 5% smooth dimming.
- No minimum load.
- Single Pole preset dimmer with on/off push switch.
- Adjustable voltage output dial to address voltage drop.
- Includes voltage barrier partition to install high and low voltage circuit in same switch box.
- No derating required when ganging units.
- Power failure memory: If power is interrupted, SWITCHEX will return to setting prior to interruption.
- 3x included face plates: Glossy White, Glossy Light Almond, and Glossy Dark Brown (trim plates not included)
Dimensions
- Width: 2.1″
- Height: 3.82″
Documents
- Spec Sheet
- Instruction Sheet
