Description

Diode LED DI-24V-TE-NBL1-63-65

DI-24V-TE-NBL1-63-65 Product

Bring the ultimate accent lighting into your project. With Zero Line Diffusion™ technology, color is saturated from end to end. Choose from multiple outputs in lengths up to 65 feet in the most popular colors. Field cuttable and easy to install with multiple mounting options.

Specifications:

Voltage: 24 Volt
Wattage: 1.22W /ft
Lumens: 88 lm/ft
Color Temperature: 6300K
Max Run: 65 ft
Cut Points: 2 in
CRI: 80+
Diffusion: Zero Line Diffusion
Dimmable: Yes
Field Cuttable: Yes
Dimensions: Height = 0.75″, Width = 0.37″
Environment: Outdoor / Wet Location / IP65
Certification: UL Listed 2108
Warranty: 5 Year
Direction: Top Bending
Tight Bend Radius
Mimics Traditional Neon
Lettering or Accent Lighting
Material: UV/IR resistant silicone
Mounting (sold separately): Bottom U-Clip, Top U-Clip
Ambient Temp: -4 – 122°F (-20 ~ 50°C)
Operating Temp: -4 – 176°F (-20 ~ 80°C)
Flammability: Flame retardant

About Diode LED:

Diode LED is America’s largest low-voltage linear lighting solutions provider and is preferred by lighting designers, architects, product specifiers, electricians, and general contractors.
