Description

Diode LED DI-12V-BLX2-30-100

DI-12V-BLX2-30-100 Product

When precision performance matters… The all new precision engineered BLAZE X is the newly enhanced LED tape light, leading the industry in lighting performance and quality. BLAZE X has 95+ CRI and higher R-Values that provides precision color rendering, superior long-lasting performance, and all with the Diode LED 12-year warranty. The X Series comes in a vast variety of higher efficiency lumen outputs for any application. You won’t find a more superior tape light in the market today.

Specifications:

Voltage: 12VDC
Wattage: 3.1W / ft
Lumens: 247/ft
Cut Points: 1 in
Max Run: 22 ft
LED Chips: 36/ft
Color Temperature: 3000K
CRI: 95+
Dimmable: Yes
Dimensions: Width = 0.32″, Height = 0.1″
Environment: Indoor / Damp Location
Certification: UL Listed 2108
Warranty: 12 Year
LED Chip Type: Epistar 2835 Guang Mau
LED Chip Beam Angle: 120°
Luminous Efficacy 3 (lm/w): 75~86
Mounting 4 : 3M™ 55280 Adhesive
Connections 5 : 3 ft. Female DC plug on end. 3 ft. hard-wire lead opposing end. Leads: UL 2464 20/2 AWG
Ambient Temp 6 : -4 ~ 122°F (-20 ~ 50°C)
Operating Temp 7 : -4 ~ 176°F (-20 ~ 80°C)

About Diode LED:

Diode LED is America’s largest low-voltage linear lighting solutions provider and is preferred by lighting designers, architects, product specifiers, electricians, and general contractors.
