Diode LED DI-12V-BLC-RD-016

DI-12V-BLC-RD-016 Product

BLAZE™ Colors delivers bright and vibrant, solid color LED light technology to any small- or large-scale environment. This enhanced tape light is backed by a 12-year warranty and the well-known service and support of Diode LED. This low-voltage LED lighting for indoor task and display lighting is built on the same dependable LED tape light design you are used to from Diode LED.

Specifications:

Voltage: 12 Volt
Wattage: 2.93/ft
Lumens: 29/ft
Max Run: 20 ft
Cut Points: 1 in
LED Chips: 36/ft
Color: Red
Dimmable: Yes
Dimensions: Width = 0.32″, Height = 0.1″
Environment : Indoor / Damp Location
Certification: UL Listed 2108
Warranty: 12 Year
LED Chip Type: 2835 Guang Mau Chip
LED Chip Beam Angle: 120°
Luminous Efficacy (lm/w): 80~98
Mounting: 3M™ 55236 Adhesive Backing
Connections: 2.5 inch hard-wire lead: 20/2 AWG
Ambient Temp: -4 ~ 122°F (-20 ~ 50°C)
Operating Temp: -4 ~ 176°F (-20 ~ 80°C)
