Description

Diode LED DI-0913

DI-0913 Product

diode led® Plug-In Adapter, Non-Dimmable, 100 to 240 VAC Input, 12 VDC Output, 60 W Power, 1.5 A, 4.7 in Length, 2 in Width, 1-1/4 in Height, 32 to 130 deg F, Plastic, White

Specifications:

Manufacturer DIODE LED
Input Voltage 100 to 240 VAC
Length 4.7 in
Width 2 in
Output Voltage 12 VDC
Power Rating 60 W
Type Non-Dimmable
Amperage Rating 1.5 A
Height __1-1/4 in
Temperature Rating 32 to 130 deg F
Material Plastic
Color White

Features:

Short circuit, over current, over voltage, over temperature protections
20 to 90% RH non-condensing working humidity
Male DC 5.5 x 2.1 mm coaxial (outside diameter x inside diameter) secondary leads
2 prong NEMA 1-15P male AC desktop plug primary connection
Fanless design, cooling by free air convection
A portable, flexible power supply
DC plug-in connection
PWM and RGB(W) dimmers/controls and DMX controls dimmability
Auto reset Hiccup circuit breakers
50 to 60 Hz frequency
32 to 104 deg F ambient temperature
1.5 A at 115 VAC full load input current

About Diode LED:

Diode LED is America’s largest low-voltage linear lighting solutions provider and is preferred by lighting designers, architects, product specifiers, electricians, and general contractors.
