Description

Core lighting IGU-20-40-05-UNV-D10

IGU-20-40-05-UNV-D10 Product

In-ground linear up light with multiple beam angle options including long, narrow pattern and optic, ideally suited for in-ground/recessed installations in concrete or lawns for wall wash and ground mounted signs and linear objects.

Features:

Wattage: 12W
Voltage: 120-277V
Color Temperature: 3000K, 4000K, 5000K
CRI: 80
Lumens: 1080, 1200, 1320
Optic: 5º, 15º, 25º, 45º, 60º
Control: 0-10V dimming
Built-in driver
Die-Cast Aluminum
Silicone Rubber Gasket
Tempered Glass Cover
Stainless Steel Top Cover Frame
Max Load: 1000 lbs

Dimensions

Length: 19.88″
Width: 2.95″
Height: 3.74″
