Description

Core lighting IGU-20-30-60-UNV-D10

IGU-20-30-60-UNV-D10 Product

In-ground linear up light with multiple beam angle options including long, narrow pattern and optic, ideally suited for in-ground/recessed installations in concrete or lawns for wall wash and ground mounted signs and linear objects.

Features:

Wattage: 12W
Voltage: 120-277V
Color Temperature: 3000K, 4000K, 5000K
CRI: 80
Lumens: 1080, 1200, 1320
Optic: 5º, 15º, 25º, 45º, 60º
Control: 0-10V dimming
Built-in driver
Die-Cast Aluminum
Silicone Rubber Gasket
Tempered Glass Cover
Stainless Steel Top Cover Frame
Max Load: 1000 lbs

Dimensions

Length: 19.88″
Width: 2.95″
Height: 3.74″

About Core Lighting

Core Lighting focus is to refine today’s illumination by developing cutting-edge and technologically advanced lighting products that are functional and energy efficient. Core Lighting has set the tone for what sets the company apart from the rest by striving for innovation, uncompromising quality and customer focused service.
