Description
APCH7RG Emergency Exit Combo
This Cooper Lighting APCH7RG LED Emergency Exit Combo Sign is the ideal choice for indoor exit and emergency signage. Adhering to UL924 standards, this light is equipped with a customizable LED heads, up to 17ft of emergency coverage, and a maintenance-free nickel-cadmium battery. LED illumination is available in red, with single or double face w/ chevrons support. Durable polycarbonate housing is universally mountable and comes in black or white. Opt for the H series to power two 3.6V emergency heads from the APWR series for top-notch lighting.
- Red / green selectable exit sign and emergency light
- Runs for 90 minutes when AC power is lost
- 3.6 V, 0.78W LED heads provide up to 17 feet of egress coverage
- Field selectable, long-life red or green LEDs and face inserts provide deep letter colors and uniform illumination
- Selectable single or double faces and snap-in/snap-out directional chevrons
- High impact, UV resistant, 5VA flame resistant housing
- Nickel cadmium battery
- Ceiling, wall and back mount with universal J-box mounting pattern
- Remote capable model powers up to two additional APWR LED heads
- UL 924 damp location listed
- Dual voltage input 120/277 VAC, 60Hz
Dimensions See Spec Sheet
| Length (in.) |
16-9/16″ |
| Width (in.) |
2-5/16″ |
| Height (in.) |
7.50″ |
|
Spec Sheets
Spec Sheet
Installation Instructions
Info
Head/Lamp Data
| AC LED: Long life LED lamps provide uniform diffused illumination |
| DC: LED DC lamps (Brighter in emergency mode) |
| Heads DC: 3.6V, .78W Long Life LED Heads Light Output Equivalent to 5.4W Incandescent |
|
Electrical
| Dual Voltage Input 120/277VAC, 60Hz |
| Line-latching |
| Solid-State Voltage Limited Charger |
| Solid-State Switching |
| Brownout Protection |
| Low Voltage Disconnect |
| Overload/Short Circuit Protection |
| Dual Voltage Input 120/277VAC 60Hz |
| Test Switch / Power Indicator Light |
| High Power Combo available capable of running two additional LED remote heads |
| 3.6V, .78W D |
|
Housing Construction
| All components are injection molded, color stable, high impact polycarbonate material |
| Reinforcing ribs throughout to provide maximum strength |
| Molded-in wireways facilitate internal wire routing and connections |
| Available in a white or black finish |
| Components are of snap-fit construction to facilitate under 5-minute installation |
| Reinforcing ribs throughout to provide maximum strength connections |
| All components including battery and electronics are located inside the exit housing |
| Snap-out or snap-in chevron directional indicators have full 3/4″ stroke |
| Universal exits can be field configured as single face or double face |
| Snap-fit canopy with mounting screws included with all exits |
| Exit can be ceiling, wall, or end mounted |
| Universal J-box mounting pattern |
| Operating temperature range 10 °C to 40 °C |
|
Additional Info
Battery
| Sealed nickel cadmium |
| Maintenance-free, long-life |
| Full recharge time: 24 hrs (max.) |
|
Code Compliance
| UL 924 Listed |
| UL Damp Location Listed |
| Life Safety NFPA 101 |
| NEC/OSHA |
| Most State and Local Codes |
| Operating temperature range 10 °C to 40 °C |
| California Energy Code compliant |
|
Warranty
| Five-year warrant |
| Seven-year prorated battery warranty |
|
