Brilliance Carlsbad Flange Low Voltage MR16 Brass Flat-Top In-Ground Well Light Outdoor Landscape Lighting

Description

The Carlsbad Flange Well Light is ideal for recessed and hardscape applications like being core drilled into concrete, pavers, and driveways. (The recommended core drill size is 2.75 inches.) The Carlsbad Flange is fitted for anyMR16 lampand comes to life with the BrillianceChameleon MR16. Like theoriginal Carlsbad fixture, the flat glass top comes in a brass finish. For a complete outdoor lighting solution, consider incorporating lighting around the pool deck to enhance both safety and aesthetic appeal

TheCarlsbad Flangefixture is available in brass. Machined brass offers a beautiful living finish that weathers over time to a unique patina.

To clean the fixture, periodically wipe it down with a mild soap and water.

To clean the fixture, periodically wipe it down with a mild soap and water.

Made in America. ETL Listed in US and Canada.

INSTALLING THE LAMP

1. Remove the rear cap and pull out the spring.

2. Set the MR16 lamp on top of the spring and plug it into the socket.

3. Insert this assembly into the fixture body with the front of the lamp toward the lens.

4. Screw the back cap onto the fixture body and hand tighten.

INSTALLING THE FIXTURE: GROUND MOUNT WITH SLEEVE

1. Dig a hole in the ground approximately 6” wide by 10” deep.

2. Connect the power cable to the fixture, leaving 2’ landscape cable coiled in the bottom of the fixture for future service.

3. Pour 8” pea gravel in the hole.

4. Place the fixture in the center of the hole.

5. Add more pea gravel to fill the hole 1” before the fixture lip. This allows for proper drainage around the fixture.

6. Apply glass wax on top of the lens to protect against standing water.

INSTALLING THE FIXTURE: CORE DRILLING WITH SLEEVE

1. Core drill a hole 2 3/4” wide by 10” deep into concrete or hardscape. Be sure there is room in the core drilled hole for proper drainage.

2. Attach the fixture cable to the main cable with the Lighting Shrink cable connection provided.

3. Insert the fixture into the sleeve and drop the fixture and sleeve into the core drilled hole.

4. Apply glass wax on top of the lens to protect against standing water.

All low voltage outdoor lights must be installed with a12V Low Voltage Transformerand connections between lights must be secured using Grease Filled Wire Nuts (WN12) waterproof connectors.
