American Lighting ADPTPRO-DR-300-24

ADPTPRO-DR-300-24 Product

The Adaptive Pro 5-in-1 dimmable drivers are designed to operate with any standard MLV / ELV / Incandescent TRIAC (forward phase) dimmer switch or can also be used with secondary side controls systems. Encased in a sealed low profile aluminum enclosure Suitable for outdoor locations.

Specifications:

Brand: American Lighting
SKU: ADPTPRO-DR-300-24
UPC: 714176023564
Input Voltage: 100-277V AC
Output Voltage: 24V DC
Input Frequency: 47-63 Hz
Output Frequency: 2.5A
Wattage: 300 W
Power Factor: 0.99 @ 120VAC, 0.95 @ 277VAC
Minimum Load: 30 W
Temperature Range: -40°C (-40°F) to 60°C (140°F)
Dimming: Phase Dimming / MLV / ELV / TRIAC 0-10V
Finish: Black
Weight: 3.90 lbs
Dimensions (W × L × H): 3.07 in × 10.8 in × 1.85 in
Safety Rating: cULus Listed
Type IC: Yes
Airtight: Yes
Location Rating: Wet
Indoor: Yes
Outdoor: Yes
ROHS: Yes
FCC: Yes

Features:

24V DC Constant voltage 300W hardwire LED driver
5-in-1 Forward and Reverse Phase Dimming:
ELV / MLV / TRIAC / 0-10V / 1-10V / 10V PWM / Potentiometer
Class I metal housing (Type HL)
8” (SJTW) Lead & Tail Wire
Short circuit, over-load, and over temperature protections
Class P / Type HL / FCC Compliant
cULus Listed – Wet location rated
