Description
Alloy LED AL-01-18-2404
AL-01-18-2404 Product
The PrimaLine Gen 2 family represents the next generation of LED lighting. Using the new, high-efficiency 2835 diode package, PrimaLine 6.6 Gen 2 offers super high output light at up to 835 lumens per foot, making it ideal for primary and large application accent lighting. PrimaLine 6.6 has a narrow form factor and its two rows of chips makes installation quick and simple. Its evenly spaced dense diode placement minimizes hotspots to provide a smooth, even line of light.
Specifications:
Manufacturer: Alloy LED
Manufacturer Part Number: AL-01-18-2404
Stocked Color Temperatures: 5000K
Lumens: 835 Lumens / FT
Power Consumption per foot: 6.6 Watts/275mA
Input Voltage: 24V DC
LED Diodes per foot: 72
Diode Spacing: 0.33 inches
Tape Width: 0.55 inches
Tape Height: 0.1 inches
Beam Angle: 120°
Field Cuttable (UL 2108): Every 1.3 inches
Maximum Run Length: 20 ft.
Dimmable: Yes
Diode Type: 2835 SMD
Mounting: 3Mâ„¢ Self-Adhesive Tape (non-porous)
Operating Temperature: -13° F to 140° F
Spool Lengths: 8 ft.
Location: Indoor, Dry
Certifications: UL Listed, RoHS, UL 2108
Standards: Certified to the CA Energy Commission in accordance with the Title 24 JA8 2016 std. (2700K – 4200K models only)
About Alloy LED:
At Alloy LED, we’re not just a lighting manufacturer and distributor—we’re your dedicated lighting partner, committed to ensuring your project’s success from start to finish. Whether you’re looking for off-the-shelf products or custom-built solutions, we provide high-quality, reliable lighting systems designed to meet your unique needs.
