Description
18 x 5W Osram high power LEDs combined with our‘Optic DriveTM’ technology to capture and focus more of the light generated to produce an extra-penetrating light output and eliminate waste. The result is 30% brighter light output than compared to a conventional LED light bar of the same length. Light bar contains Osram high power LEDs in a one-piece die-cast aluminum housing with 580mm pre-wired lead, genuine Nitto breather vent and weatherproof DT connector.
Features:
- Durable Cast Aluminum Housing
- High Power Osram LEDs
- Genuine NittoBreather Vent
- Weatherproof DT Connector
Item #:UT-72274-2
Specifications
|
Product LxWxH |
— |
| Input Voltage |
9-32V |
|
Amp Draw |
3.7A @ 12V |
| LEDs | 18x 5W Osram high power LEDs |
| Watts |
90W |
|
Raw Lumens |
9,000 lm |
| Lux | 1 Lux at 345m |
| IP Rating | IP68 & IP69K |
| Operating Temp | -30°C to 65°C |
| Color Temperature | 5700°K |
| Size | 22′ or 550mm |
| ECE | ECE R10 |
| Other | Active Thermal Heat Management System (ATMS) |
Downloads
—-
